51.2V 314AH Rack Mounted Lithium Battery, Life04 battery.
It can be widely used for commercial and industrial use.
Paiement :
30% by T/T in advancePort d'expédition :
Shanghai or NingboDélai de mise en œuvre :
10-15 working days after paymentsAdvantages:
| Battery Specification | PNG30KW-60kWh |
|
Number of Battery Packs
|
6 |
|
Rated Voltage
|
307.2V
|
|
Voltage Range
|
268.8~350.4V
|
|
Rated Energy
|
60kWh
|
|
Discharging Current
|
100A
|
|
Communication
|
RS485/CAN
|
|
Cycle Life
|
6000 times
|
|
PV Specification
|
|
|
Max.PV Input Power
|
39kW
|
|
Rated Input Voltage
|
600VDC
|
|
Max.Input Voltage
|
1000VDC
|
|
MPPT Voltage Range
|
200~850VDC
|
|
AC Side Specification
|
PV Input Current
|
|
AC Rated Input/Output Power
|
|
|
AC Max. Input/Output Power
|
30kVA
|
|
AC Rated Input/Output Current
|
33kVA
|
|
AC Max. Input/Output Power
|
45.6A
|
|
Voltage
|
60A
|
|
Frequency
|
3L/N/PE; 230/400V
|
|
THDi
|
50/60Hz
|
|
Power Factor
|
≤3%
|
|
System Specification
|
0.8 leading to 0.8 lagging
|
|
Dimension（W*H*D）
|
840*1045*1550mm
|
|
Weight
|
960kg
|
|
Communication
|
CAN/RS485/WiFi/ETH
|
|
Warranty
|
10 years
|
|
Protection Level
|
IP55
|
|
Cooling
|
Air-cooling
|
|
Environment temperature
|
-30~50℃
|
|
Humidity
|
10%~95%RH
|
|
Altitude
|
<2000m
|
|
Certifications
|
UN38.3/CE/IEC62619/CEI 0-21/VDE-AR-N 4105/IEC 62109
|
FAQ:
1: Can the product be shipped to my area?
We export to most countries/regions (Centre/ South America, EMEA, SEA, SSA, AU). We will check and confirm for you after you provide the region.
2: How can I make payment?
100% T/T or maximum we can accept 30% T/T in advance and 70% T/T upon goods ready before shipment.
